Improvements to Display Effect:
Image Booster (Effects depend on the driver IC)
− Color Management: Allow users to freely
switch the color gamut of the screen
between different gamuts in real time to
enable more precise colors on the screen.
− Precise Grayscale: Individually correct the
65,536 levels of grayscale (16bit) of the
driver IC to fix the display problems at low
grayscale conditions, such as brightness
Pixel level brightness and chroma calibration
Work with NovaStar’s high-precision calibration
system to calibrate the brightness and chroma of
each pixel, effectively removing brightness
differences and chroma differences, and
enabling high brightness consistency and
chroma consistency.
Quick adjustment of dark or bright lines
The dark or bright lines caused by splicing of
cabinets or modules can be adjusted to improve
the visual experience. This function is easy to
use and the adjustment takes effect immediately.
Low latency
The latency of video source on the receiving
card end can be reduced to 1 frame (only when
using modules with driver IC with built-in RAM).
3D function
Working with the sending card that supports 3D
function, the receiving card supports 3D image
output.
Individual gamma adjustment for RGB
Working with NovaLCT (V5.2.0 or later) and the
sending card that supports this function, the
receiving card supports individual adjustment of
red gamma, green gamma and blue gamma,
which can effectively control image nonuniformity at low grayscale conditions and white
balance offset, allowing for a more realistic
image.
Image rotation in 90° increments
The display image can be set to rotate in
multiples of 90° (0°/ 90°/180°/270°).
Image rotation at any angle
Working with SmartLCT and the MCTRL R5 LED
display controller, the receiving card supports
image rotation at any angle.
HDR
HDR10 and HLG are supported.
Work with the sending card that supports the
HDR function to correctly parse the HDR video
source and faithfully reproduce the original
brightness range and color space, allowing for a
more lifelike image.
