Improvements to Display Effect:
Thermal Compensation 2.0
Full Grayscale Calibration
LED Image Booster (Effects depend on driver IC)
- Color Management: Support the standard color
gamuts (Rec.709, DCI-P3 and Rec.2020) and
custom color gamuts, enabling more precise
colors on the screen.
- Precise Grayscale: Individually correct the
65,536 levels of grayscale (16bit) of the driver
IC to fix the display problems at low grayscale
conditions, such as brightness spikes,
brightness dips, color cast and mottling. This
function can also better assist other display
technologies, such as 22bit+ and individual
gamma adjustment for RGB, allowing for a
smoother and uniform image.
- 22bit+: Improve the LED display grayscale by
64 times to avoid grayscale loss due to low
brightness and allow for more details in dark
areas and a smoother image.
HDR
- Support HDR10 and comply with the SMPTE
ST 2084 and SMPTE ST 2086 standards.
- Support HLG.
Frame Rate Adaptive 3.0
Adjust the receiving card parameters in real time
according to the input frame rate, so that the
display effect at different frame rates (23 Hz to 240
Hz) is the best.
Shutter Fit
Quick adjustment of dark or bright lines
Low latency
Pixel level brightness and chroma calibration
Work with NovaStar’s high-precision calibration
system to calibrate the brightness and chroma of
each pixel, effectively removing differences and
enabling high consistency for both brightness and
chroma.
3D
Working with the controller that supports 3D
function, the receiving card supports 3D output.
Image rotation in 90° increments
The display image can be set to rotate in multiples
of 90° (0°/90°/180°/270°).
