ET16S-G(2A4) Mainframe
Cikkszám:
M10010246

The ET16S-G media server is the latest offering from NovaStar, boasting a 16K ultra-high
resolution, pixel-to-pixel screen loading, and multiple high-performance graphics cards.
Equipped with a powerful workstation motherboard, Intel Xeon processor, and ECC high-speed
memory, the ET16S-G enables flawless frame-synchronized output of four graphics cards. A single
ET16S-G media server can replace four traditional media servers with single graphics card
configurations, while also having the ability to link multiple servers for frame-synchronized mosaic
and backup, perfect for meeting the requirements of ultra-high resolution displays exceeding 16K.

ET16S-G(2A4) Mainframe
ET16S-G(2A4) Mainframe
ET16S-G(2A4) Mainframe
ET16S-G(2A4) Mainframe
ET16S-G(2A4) Mainframe
ET16S-G(2A4) Mainframe
1
6
Details

Chassis: 4U
Memory Size: 64G（DDR4）
CPU: Single Intel Xeon Gold Processor
Storage: 1TB M.2 SSD

Ghraphics Cards Model: 2x HPG4000, 1xMPGT400, 1xSync Card
Loading Capacity: 8× 4096×2160@60Hz
Decoding Capacity: 2 layers of 8K@60 or 8 layers of 4K@60
Program Quantity: Unlimited
Layer Quantity: 12 layers (24 layers with 2 graphics cards, 36 layers with 3 graphics cards, 48 layers with 4 graphicscards) and 1 audio layer, with supported for expandability
EDID Lock: Yes
Cascading: Yes

Frame Synchronization Splicing: Yes
Dual-machine Backup: Yes
Ipad Control: Yes
Protocol Control: Yes
Operation System: Windows 10 Enterprise LTSC

Software: Kompass FX3 (Dongle Included)
Media Type: Video, audio, picture, subtitle, PPT, web page, NDI, streaming media, collection playback, capture card, digital clock, sequence frame



Specifications
