1x RJ45 Gigabit Ethernet input
 Supports 8-bit YUV4:2:2 or YUV4:2:0 input decoding.
 Single card decoding capability:
− 4x 2K×1K@60Hz
− 2x 4K×1K@60Hz
− 1x 4K×2K@60Hz
 Supports input source cropping.
 DHCP supported
 Supports video decoding in Full NDI format.
 Does not support standard and custom resolution settings for the input source.

Status LEDs:
 Green: Indicating the input source access status
− On: The input source is accessed normally.
− Off: No input source is accessed.
 Yellow: Indicating the input source status
− On: The input source is normal.
− Off: The input source has no signal or the input source is abnormal.
− Flashing: The connector is in communication.

Specifications:
 Weight: 500 g
 Dimensions: 193 mm × 247.12 mm × 21.15 mm
 Power consumption: 42 W
