Support for single link and dual link input modes, 10-bit input source and 144Hz input
HDCP 1.4 compliant
Does not support interlaced signal input.

 Single link mode:
− Four DVI connectors are all used for input.
− Each connector supports the maximum resolution of 2048×1152@60Hz and
   the minimum resolution of 800×600@59.94Hz.
− Custom resolutions:
Max. width: 2560 pixels (2560×983@60Hz)
Max. height: 2560 pixels (884×2560@60Hz)

 Dual link mode:
− Connectors 2 and 4 are used for input, and connectors 1 and 3 are
    unavailable.
− Each connector supports the maximum resolution of 3840×1080@60Hz and
    the minimum resolution of 800×600@59.94Hz.
− Custom resolutions:
Max. width: 3840 pixels (3840×1202@60Hz)
Max. height: 3840 pixels (1092×3840@60Hz)

Status LEDs:
 On: The input source is accessed normally.
 Off: No input source is accessed or the input source is abnormal.

Specifications:
 Weight: 550 g
 Dimensions: 193 mm × 247.12 mm × 21.15 mm
 Power consumption: 9.4 W
