Type: 12G-SDI

Qty: 4

Descriptioin:

- Standards: Support ST-2082 (12G), ST-2081 (6G), ST-424 (3G) and ST292 (HD) standard video inputs.

  Support 3G-Level A/Level B (DS mode).

- Max resolution: 4096×2160@60Hz

- Min resolution: 720x480i@59.94Hz

- Max width: 8192 pixels (8192×4320@30Hz)

- Max height: 8192 pixels (4320×8192@30Hz)

- Frame rate: 23.98/24/25/29.97/30/47.95/48/50/59.94/60 Hz

- HDR: HDR video is accepted with manual HDR configuration in VMP.

- EDID management: Support standard resolutions, up to 3840×2160@60Hz. Support custom input resolutions.

- HDCP: HDCP 2.3 compliant, backwards compatible with HDCP 2.2/HDCP 1.4/HDCP 1.3.

- Interlaced signal inputs: Support interlaced signal inputs, including 1080i/576i/480i

- Cables: Recommend using the CANARE-12G SDI coaxial cable. Cables up to 50 meters are supported.
