NS060-10A
Cikkszám:
M09020046

The NS060 is a light sensor that can be connected to sending cards, asynchronous cards or
multifunction cards for ambient brightness monitoring, allowing for automatic brightness
adjustment of LED display.
The sensor body of NS060 is made of aluminum alloy. The sensor surface adopts micro-arc
oxidation process, and therefore it is highly UV-resistant and will not be discolored. The joint
between the sensor body and the male connector has a very deep groove and is extremely
waterproof.

NS060-10A
Details

Features:
 Ambient brightness monitoring, allowing for automatic brightness adjustment of LED display

 Capable of connecting to sending cards (MSD300, MSD600, MCTRL300, etc.), asynchronous
    cards or multifunction cards
 Standard 5-meter cable included, with options for 10, 30, or 100 meters
 Mildew, moisture and salt-mist resistant design, ideal for outdoor applications
 No external power supply required

Specifications:

 - Rated voltage: 5 V DC

 - Maximum current: 0.09 A

 - Maximum power consumption: 0.45 W

 - Operating temperature: –20°C to +70°C

 - Operating humidity: 0% RH to 99% RH, non-condensing

 - Brightness measurement range: 0 lux to 65535 lux

 - Cable length: 10 m (NS060-5A model)

 - IP Rating: IP65



Note:

The maximum current and power consumption were tested for a single light sensor under
conditions of 5V input voltage at an ambient temperature of 25°C.
