Details

Input

Output

 1x HDMI 1.3 connector In synchronous mode, video sources input from this connector can be scaled to fit the entire screen automatically.  2x Sensor connectors Connect to brightness sensors or temperature and humidity sensors.

 Loading capacity up to 1,300,000 pixels − Maximum width: 4096 pixels Maximum height: 4096 pixels − Non-standard resolutions can be customized in both asynchronous and synchronous modes and the pixel clock of the custom resolutions cannot exceed 153 MHz.  2x Gigabit Ethernet ports These two ports serve as primary by default. Users can also set one as primary and the other as backup.  1x Stereo audio connector The audio sample rate is fixed at 48 kHz. If NovaStar’s multifunction card is used for audio output, audio with a sample rate of 48 kHz is required.  1x HDMI 1.3 connector − Maximum output: 1920×1200@60Hz − Support for HDMI loop



Control
 1x USB 3.0 (Type A) port
Allows for USB playback, firmware upgrade
and storage expansion.
 1x USB (Type B) port
Connects to the control computer for content
publishing and screen control.
 1x Gigabit Ethernet port
Connects to the control computer, a LAN or
public network for content publishing and
screen control.



Performance
 Powerful processing capacity
− Quad-core ARM A55 processor @1.8 GHz
− Support for H.264/H.265 4K@60Hz video
decoding
− 1 GB of onboard RAM
− 32 GB of internal storage
 Flawless playback
Support for playback of 2x 4K, 6x 1080p, 10x
720p, or 20x 360p videos
